Опис
| Model |
LICG36SNP |
LICG36SHE
|
LICG36HNB
|
LICG36SHD
|
LICG36HHB
|
LICG36SE
|
LICG36HM | LICG36SM | |
| Image Sensor |
1/3″ SONY
|
1/3″ SONY
|
1/3″ SHARP
|
1/3″ SONY
|
1/3″ SHARP
|
1/3″ SONY
|
1/3″ CMOS | 1/3″ CMOS | |
| Horizontal Resolution |
700TVL, Low Illumination, Super WDR, 3D NR, Demist, SLR, Sense-up, UTC
|
700TVL, Low Illumination, DWDR, OSD, DNR, UTC Effio-E
|
700TVL, Low Illumination, DWDR, OSD, DNR
|
650TVL, Low Illumination, DWDR, OSD, DNR
|
600TVL, Low Illumination
|
500TVL, Low Illumination
|
700TV Lines Low Illumination
|
960H, 800TVL, With IR-CUT | |
| Pixels |
NTSC:976(H)×494(V),
PAL:976(H)x582(V ) |
NTSC:768(H)×494(V),
PAL:752(H)x582(V) |
PAL:752(H)×582(V),
NTSC:768(H)×494(V) |
PAL:500(H)×582(V)
NTSC:510(H)×492(V) |
728(H)×488(V) | 976(H)×496(V) | |||
| TV System |
PAL/NTSC
|
||||||||
| IR LED |
?5X36PCS
|
||||||||
| IR Series Distance |
30M
|
||||||||
| Lens |
CS Lens 6mm/F2.0
|
||||||||
| Sync System |
Internal
|
Internal, Negative sync | |||||||
| Usable Illumination |
0.001Lux/F2.0
|
0.01Lux/F2.0
|
0.001Lux/F1.2 | 0.01Lux /F1.2 | |||||
| S/N Ratio |
≥52dB (AGC OFF)
|
≥52dB (AGC OFF) | ≥46dB (AGC OFF) | ≥48dB (AGC OFF) | |||||
| Gamma Correction |
0.45
|
||||||||
| Video Out |
Composite Signal (1.0Vp-p, 75Ω)
|
||||||||
| Scanning System |
PAL:625 Lines, 50 Field/Sec;NTSC:525 Lines, 60 Field/Sec
|
||||||||
| Electronic Shutter Time |
Auto:PAL 1/50-1/100, 000Sec;NTSC 1/60-1/100, 000Sec
|
||||||||
| Operation Temperature |
-10? ~ +50? RH95% Max
|
||||||||
| Storage Temperature |
-20? ~ +60? RH95% Max
|
-30~+60? RH95% MAX | |||||||
| White Balance |
Auto
|
||||||||
| Power Source |
DC12V 500mA
|
DC12V (+/-10%)/450mA | |||||||
| Dimension |
213(W) x 93(H) x 83(D)mm
|
||||||||
| Package | 53*39*37 18PCS 12.8KG | ||||||||
| Weight |
880g
|
||||||||
